35W HID Electronic Ballast
1. SIZES AND PICTURES OF PRODUCTS
Shape Of 35W HID
L x W x H ( 122.6×76.5×33.5mm )

PCB OF 35W
L x W x H ( 119×72.3×12mm )

2. INPUT AND OUTPUT DATA

(1). Table 1: INPUT CHARACTER
MODEL
INPUT VOLTAGE
V
INPUT CURRENT
A
INPUT POWER
W
HD CURRENT %
PFλ
MAX START CURRENT
A （≤）
MIN START VOLTAGE
V
3 times
5 times
CETC-HID35B001
110
0.36
41±1
1.9
0.1
≥0.98
1
88
CETC-HID35A001
220
0.18
41±1
6.8
4.0
≥0.95
0.5
176


(2). Table 2: OUTPUT CHARACTER
MODEL
LAMP VOLTAGE
V
LAMP CURRENT
mA
LAMP POWER
W
TRIGGER VOLTAGE
V
FREQUENCY
Hz
MAX START VOLTAGE V
MAX START CURRENT A
VOLTAGE FOR BLOWING OUT OF ARC
V
CETC-HID35B001
83±15
410±35
36±0.5
≤4000
≤400
4000
2
<85
CETC-HID35A001
83±15
410±35
36±0.5
≤4000
≤400
4000
2
<160

(3). INPUT VOLTAGE RANGE: ≤±20% of rated voltage when electronic ballast work normally.
(4). INPUT CURRENT RANGE: ≤±5% of data listed in table 1 if working under rated voltage.

3. LIGHT DATA
MODEL
COLOR RENDER
COLOR TEMPERATURE
LUMINOUS FLUX
CETC-HID35B001
>80
>3000K
>3100Lm
CETC-HID35A001
>80
>3000K
>3100Lm

4. FUNCTION
(1). OPEN AND SHORT CIRCUIT PROTECTION.
(2). RESTART FUNCTION.
(3). WORKING UNDER WIDE VOLTAGE AND RATED POWER.
(4). COMPATITBLE（FIT FOR BULB MADE OF QUARTZ AND CERAMIC.

5. PRODUCT SIZE AND DIMENSIONS
